Parameter Specification
WingSpan: 1400mm(55in)
Full Length: 1020mm(40in)
Flight Weight: 1.55kg
Wing Area: 34.67d㎡
Wing Load: 44.7g/d㎡
Wing Angle of Incidence: 1.5°
Motor Thrust Angles: Down2.5°&Right 4°
Pack Dimension: 107*32*25 (L*H*W)cm
Gross Weight: 7.35KG
The Center of Gravity (CG)
Approx. 70-75mm(measured from wing leading edge at root)
Power System
Motor: Sunnysky 2820
ESC: Sunnysky 40A
Propeller: Eolo 13x7E/12x6.5E
Lipo battery:3S/4S 2200-2600mah
Servo
OMPHOBBY SG5 17g *4 : (Aileron*2,Elevator*1, Rudder*1)
Cord/lead: 600mm*4
Servo Arm: 17g, 0.9"plastic servo arm
Recommended Settings of Dual Rates and Exponential of Control Surfaces
Aileron: Low rate 60 deg. 50% expo
High rate 100 deg. 40% expo
Elevator: Low rate 50 deg. 40% expo
High rate 100 deg. 30%expo
Rudder: Low rate 60 deg. 40% expo
High rate 100 deg. 30% expo
